The Hithium HEROEE 16 51.2V 16kWh LiFePO4 Lithium Battery is a high-performance energy storage solution designed for residential and commercial solar applications. Here are the key details:
- Nominal Voltage: 51.2V, making it compatible with 48V systems commonly used in solar energy storage.
- Capacity: 16kWh, providing substantial energy storage for daily use, suitable for powering homes or small businesses.
- Chemistry: Utilizes Lithium Iron Phosphate (LiFePO4), known for its safety, stability, and long lifespan.
- Cycle Life: Rated for 11,000 cycles, ensuring durability and reliability over an extended period, typically exceeding 10-15 years with proper use.
- Warranty: Comes with a 7-year warranty, reflecting confidence in its longevity and performance.
- Maintenance: Zero maintenance required, thanks to its robust design and built-in management system.
- Battery Management System (BMS): Features a smart BMS that monitors and optimizes battery performance, ensuring safety and efficiency by managing voltage, current, and temperature.
- Certification: IEC certified, meeting international safety and quality standards.
- Interface: Includes a PC interface, allowing users to monitor and manage the battery’s status via a computer.
- Applications: Ideal for home energy storage, backup power, and integration with solar systems to maximize renewable energy use.
🔋 Hithium HeroEE 16 – Lithium Battery Datasheet
| Item | Specification |
|---|---|
| Battery Chemistry | Lithium-iron phosphate (LiFePO₄) |
| Battery Capacity | 16kWh |
| Battery Cell Lifespan | 11,000 cycles (@25°C, 100% DOD, 0.5P, 70% SOH) |
| Product Lifespan | >8000 cycles (@20–25°C, 100A, 90% DOD) |
| Rated Voltage | 51.2V DC |
| Discharge Voltage Range | 43.2V – 56.8V DC |
| Charge Voltage Range | 43.2V – 56.8V DC |
| Recommended Charge/Discharge Current | 100A |
| Maximum Charge/Discharge Current | 200A |
| Depth of Discharge (DoD) | 90% |
| Charge Mode | CC – CV |
| Charge/Discharge Port | M8 Bolt |
| Communication Ports | CAN / RS485 / RS232 / WiFi / Bluetooth (Optional) |
| Display | Yes, LCD Touchscreen |
| Scalability | Up to 16 batteries (Max 256kWh) |
| Compatible Inverter Brands | Hithium, Victron Energy, Deye, Voltronic, SMA, GoodWe, Growatt, etc. |
| IP Rating | IP30 |
| Operating Temperature | Charging: 0°C ~ 40°C Discharging: -20°C ~ 40°C |
| Storage Temperature | -20°C ~ 60°C |
| Protection | Over-temperature, Under-voltage, Over-charge, Over-current, Short-circuit, Reverse connection, Fault protection |
| Humidity | 10% – 90% RH |
| Operating Altitude | ≤3000m |
| Cooling System | Natural cooling |
| Dimensions (mm) | Without box: 540.6 × 240 × 781.2 With box: 600 × 320 × 1120 |
| Weight | Net: 110kg Gross: 135kg (with wooden box) |
| Wheels | 4 Wheels |
| Certification | UN38.3 / MSDS / IEC62619 |
🔋 Hithium HeroEE 16 – 16kWh Lithium Battery (LiFePO₄)
- ✅ Battery Chemistry: Lithium-iron phosphate (LiFePO₄)
- ✅ Battery Capacity: 16kWh
- ✅ Battery Life: 11,000+ cycles (@25°C, 100% DOD)
- ✅ Rated Voltage: 51.2V DC
- ✅ Charge Current: 100A (Recommended)
- ✅ Discharge Current: 200A (Max)
- ✅ Communication: Built-in CAN / RS485 / RS232 / Bluetooth
- ✅ Display: LCD Touchscreen
- ✅ Scalability: Connect up to 16 batteries (Max 256kWh)
- ✅ Compatible Inverters: Hithium, Victron, Voltronic, SMA, Growatt, etc.
- ✅ IP Rating: IP30
- ✅ Temperature Range: Charging: 0°C–40°C | Discharging: -20°C–40°C
- ✅ Cooling System: Natural cooling
- ✅ Protection: Over-temp, Over-voltage, Over-charge, Short-circuit, Fault Protection
- ✅ Dimensions: 540.6 × 240 × 781.2 mm (without box)
- ✅ Weight: 110kg (Net) / 135kg (Gross with wooden box)
- ✅ Certifications: UN38.3 / MSDS / IEC62619
- 🛡️ Warranty:
- 🔧 5 Years Warranty (Warranty will be provided by Hithium Bangladesh)
